This meter is ideal for flow measurement in many different industries, and is particularly well suited to Oil & Gas applications such as:

  • Midstream transportation of oil & gas
  • Rail car & truck loading
  • Allocation metering in crude oil and natural gas production
  • Well servicing and completions equipment
  • Refined downstream production products

Technical Specs:

  • Nominal meter size: DN 10 - 300
  • Features:
       » DSP-technology based Coriolis flow measurement
       » Multivariable capability for mass flow rate, volume,       density and temeperature measurement
       » Accuracy over a wide flow range
       » No flow conditioning or straight pipe runs required
  • Approval: CE (LVD 2006/95/EC), Exd (ib) IIC T4
  • Basic accuracy: ±0.1%, 0.2%, 0.% of flow reading
  • Output: 4-20ma, HART, Pulse, RS-485 (MODBUS-RTU)
  • Media temperature range: -150 ~ 400°C

Materials of Construction:

  • Sensor Tubes: 316L SS Seamless tubing
  • Flow Diverter:  304 SS
  • Flange:  304 SS
  • Indicator:  Cast Aluminum
